Computing polynomials: outperforming C++

#metaprogramming #demo

When you want to convince people that Julia is the best language for some task, some are easily swayed by the beautiful syntax, rank polymorphism, and flirtations with functional programming. In all honesty, those people need little convincing. Others want to see hard numbers!

Here's a very small demo that shows how Julia can outperform any traditional language: computing polynomials.

Suppose we have a function described by

f(x)=∑cixi, f(x) = \sum c_i x^i,

where we have the coefficients stored in some dense vector.

struct Polynomial{T}
    c::Vector{T}
end
Enter fullscreen mode Exit fullscreen mode

We can evaluate this function as follows:

function (f::Polynomial{T})(x::T) where T<:Number
    result = f.c[1]
    xpow = x
    for c in f.c[2:end-1]
        result += xpow * c
        xpow *= x
    end
    result + xpow * f.c[end]
end
Enter fullscreen mode Exit fullscreen mode

This is very much how you would implement such a function in most other languages. In Julia however, we can do something much nicer: generate a function.

function expand(f::Polynomial{T}) where T<:Number
    :(function (x::$T)
        r = $(f.c[1])
        xp = x
        $((:(r += xp*$c; xp*=x) for c in f.c[2:end-1])...)
        r + xp * $(f.c[end])
    end)
end
Enter fullscreen mode Exit fullscreen mode

Now, when we expand(f), say we have f = Polynomial(1.0, 0.5, 0.333, 0.25) the generated function will look as follows:

:(function (x::Float64,)
      r = 1.0
      xp = x
      begin
          r += xp * 0.5
          xp *= x
      end
      begin
          r += xp * 0.333
          xp *= x
      end
      r + xp * 0.25
  end)
Enter fullscreen mode Exit fullscreen mode

To run this, we say f_unroll = eval(expand(f)). Not only does this run much faster than our previous loopy implementation, it even outperforms C++ (GCC at -O3) by more than a factor of two (depending on your machine). The reason is that we have no loop in our generated code, and more importantly, we are not accessing any memory. We have done something that a C++ programmer wouldn't dream of doing: write a code generator, compile the specialised code, and fly to the moon!

A completely literate and Documentered implementation of this demo can be found here.

Edit: Thanks to Nicos Pitsianis for point out to me that there is a more efficient method called Horner's method. This method applies to both Julia and C++ implementations, reducing the amount of multiplications needed. Using this method reduces the difference between Julia and C++ a little bit, but increasing the order of the polynomial grows it back again.

Top comments (5)

Collapse

rolandka profile image
Roland Schätzle •

I've tried to reproduce the benchmarks of all three versions of the algorithm, you presented in "A completely literate and Documentered implementation ...". There are three variants presented (variant 2 and 3 are shown in the post above).

My environment is Julia 1.9.1 on Apple M1. I've used the @benchmark-macro from the BenchmarkTools-package. This macro calls the expression to be measured several hundred times in order to obtain a reliable statistics. So there is no need for the functions test_f1, test_f2 and test_f3. I've basically evaluated the expression inside these functions (which is more or less equivalent to calling these functions with n = 1).

This resulted in the following run times in ms for evaluating 100,000 arguments with variants 1-3: 6.35/2.30/0.15 (original in the table below).

Then I tried to insulate the pure algorithm a bit more, eliminating other effects which may degrade run time. There are basically two aspects:

  • Using global variables (for the polynomial f and its arguments xs) isn't recommended for the Julia compiler. It is better to pass them as function arguments of to declare them as const. It did the latter.
  • The LinRange for the arguments uses lazy evaluation. I.e. the numbers are only created when needed for evaluation. So I applied a collect on them in order to pre-allocate all arguments.

Using const values is a huge improvement for variant 2. So the speedup from variant 2 to 3 gets much smaller (but still is great).

The following table shows all results and the speedups based on these numbers. For comparison I've also added the numbers of the Julia standard function evalpoly.

Image description

Collapse

pitsianis profile image
Nikos Pitsianis •

Shouldn't it be faster if you used Horner's rule to evaluate the polynomial? It would require a single multiplication (instead of two) and a single addition per coefficient.
The unrolled code will also be shorter.

Collapse

jhidding profile image
Johannes Hidding •

Thanks for the tip! I'll add this to the code.

Collapse

nsajko profile image
Neven •

Note that Julia Base has a function for evaluating a polynomial given by coefficients: Base.Math.evalpoly:
docs.julialang.org/en/v1/base/math...

On the other hand, when you're willing to preprocess the polynomial (prior to evaluating it lots of times), techniques that may be faster than evalpoly are possible.

Collapse

fortunewalla profile image
Fortune Walla •

Very interesting. Also something that most are unaware of. i.e literate programming. 👍
